MyPBX U200

Users: 200

Concurrent Calls(Max): 50

Voicemail: 3000min , Up to 16 Analog Port(FXO/FXS)s,Up to 8 GSM Ports  ,Up to 8 BRI Ports

LAN: 1 (10/100Mbps) ,WAN: 1 (10/100Mbps)

Auto-Recording(Add-on): Support

MyPBX STANDARD

Users: 100

Concurrent Calls(Max): 25

Voicemail: 3000min , Up to 16 Analog Port(FXO/FXS)s,Up to 8 GSM Ports  ,Up to 8 BRI Ports

LAN: 1 (10/100Mbps) ,WAN: 1 (10/100Mbps)

MyPBX U500

Users: 500

Concurrent Calls(Max): 80

Voicemail: 3000min , Up to 16 Analog Port(FXO/FXS)s,Up to 8 GSM Ports  ,Up to 8 BRI Ports,LAN: 1 (10/100Mbps) ,WAN: 1 (10/100Mbps)

Auto-Recording(Add-on): Support

Hard Disk: Support 2.5 inch SATA2 (Optional)

MyPBX-U520

Users: 500

Concurrent Calls(Max): 80

Voicemail: 3000min , Up to 16 Analog Port(FXO/FXS)s,Up to 8 GSM Ports  ,Up to 8 BRI Ports

LAN: 1 (10/100Mbps) ,WAN: 1 (10/100Mbps)

Auto-Recording(Add-on): Support

Hard Disk: Support 2.5 inch SATA2 (Optional)

MyPBX U100

Users: 100

Concurrent Calls(Max): 25

Voicemail: 3000min , Up to 16 Analog Port(FXO/FXS)s,Up to 8 GSM Ports  ,Up to 8 BRI Ports

LAN: 1 (10/100Mbps) ,WAN: 1 (10/100Mbps)

Auto-Recording(Add-on): Support

MyPBX SOHO

Users: 32

Concurrent Calls(Max): 15

Voicemail: 3000min , Up to 4 Analog Ports (FXO/FXS) ,Up to 4 BRI Ports

LAN: 1 (10/100Mbps)

\MyPBX U300

Users: 100

Concurrent Calls(Max): 50

Voicemail: 3000min ,One E1/T1/J1 ports (Support PRI,MFC R2,SS7), 2 FXS Ports

    One RS232 Port ,LAN: 1 (10/100Mbps) ,WAN: 1 (10/100Mbps)

Auto-Recording(Add-on): Support\\

MyPBX U510

Users: 500

Concurrent Calls(Max): 80

Voicemail: 3000min , Up to 16 Analog Port(FXO/FXS)s,Up to 8 GSM Ports  ,Up to 8 BRI Ports

LAN: 1 (10/100Mbps) ,WAN: 1 (10/100Mbps)

Auto-Recording(Add-on): Support

Hard Disk: Support 2.5 inch SATA2 (Optiona

S2 Module(2 FXS Ports)

The S2 is a module with 2 FXS ports to terminate two analog telephone.

      It can be used in MyPBX SOHO, MyPBX Standard, MyPBX Pro, MyPBX E1, MyPBX Enterprise, MyPBX U100, MyPBX U200, MyPBX U5XX

B2 Module(2 BRI Ports)

The B2 is a module with 2 BRI ports to terminate two BRI lines.

      It can be used in MyPBX SOHO, MyPBX Standard, MyPBX Pro, MyPBX Enterprise, MyPBX U100, MyPBX U200, MyPBX U5XX and NeoGate TB400

O2 Module(2 FXO Ports)

The O2 is a module with 2 FXO ports to terminate two analog PSTN(POTS) lines.

      It can be used in MyPBX SOHO, MyPBX Standard, MyPBX Pro, MyPBX E1, MyPBX Enterprise, MyPBX U100, MyPBX U200, MyPBX U5XX

 SOModule(1FXS&1 FXO)

Unique PSTN Fallback Function! Make/receive calls even when system power break down.

      It can be used in MyPBX SOHO, MyPBX Standard, MyPBX Pro, MyPBX E1, MyPBX Enterprise, MyPBX U100, MyPBX U200, MyPBX U5XX

GSM Module(1 GSM Port)

The GSM is a module with 1 GSM port to terminate GSM network.

      It can be used in MyPBX Standard , MyPBX Pro,MyPBX Enterprise, MyPBX U100, MyPBX U200, MyPBX U5XX and NeoGate TG200

Yeastar MyPBX is a powerful hybrid Asterisk IP PBX telephone system for small and medium-sized enterprises, institutions etc.Yeastar Mypbx will support gsm lines analogue public and internal connections, and ISDN BRI or PRI connections. The software is based on Asterisk VoIP system with MyPBX hardware ensures reliable and functional activity.
